ASP42T Antenna Splitter- Wireless Microphone  1u Quad 2 way-TNC - GTD

bodymics Antenna

ASP42T Antenna Splitter- Wireless Microphone 1u Quad 2 way-TNC - GTD

$ 199.00 $ 249.99

ASP42T -  1u Quad 2 way Passive Antenna Divider with TNC Connectors
Shallow 1u form factor - only needs about 4" behind other equipment - less compact than BNC version
4x wide-band transformer splitters - suit UHF and VHF - mounted on the panel
Fitted with 4x TNC panel connector on front panel to accept TNC terminated antennas
Comes with 8 cables with TNC connectors (or adapters) on the receiver end

Use with any wireless systems that use TNC antenna connectors rather than BNC, including:



Bodymics is a US based Manufacturer and
Distributor of Wireless Microphones Accessories
  • Frequency Range:     150MHz-900MHz
  • Insertion Loss:  ~3.5dB @150Mhz; -36dB @ 550MHz; -38dB @ 750MHz
  •  (theoretical loss is at least 3dB despite some manufacturers's claims)
  • All fitted on a 19" x 1.75" rack mount panel
  • Needs between 3 and 4" of mounting depth (including connectors)
  •
  • List Price - $549.99     MAP/Street Price $459.99
  • 1 year Warranty - Faulty Materials and Workmanship

In the package:
  • ASP42T 1u Panel with splitters and TNC Antenna connectors
  • 8x TNC flyleads - 500mm
  • Instructions
